Roj teeb Charge fuses
Kev ntsuas hluav taws xob: DC 500V
Kev ntsuas tam sim no: 10A-500A
Class: aR
Txuj: UL{0}}, ISO8820, JASO-D622, IEC60269, RoHS raws
Daim ntawv thov: luv-circuit thiab thaub qab tiv thaiv rau hluav taws xob tsheb tsav lub zog, lub zog hloov dua siab tshiab, lub zog cia thiab fais fab roj teeb, lub zog cia capacitor, inverter maub los, charger, MSD, hlau thiab lwm yam khoom siv tsheb thiab khoom siv.
If any further demand,pls feel free to contact by email:holly@delfuse.com or whatsapp by 8618813915908
Xa kev nug
Product Details ofRoj teeb Charge fuses
DC 500V round tube bolted fuses tsuas yog siv rau EV roj teeb thaub qab tiv thaiv
Specification ntawm EV-HQ fuses
|
Rated Voltage |
AC / DC 500V |
Hom Kev Tiv Thaiv |
aR |
|
Rated Tam sim no |
10A-500A |
Txhaum Muaj Peev Xwm |
AC 100 KA, DC 20 KA |
|
Ua raws li qhov yuav tsum tau ua |
UL{0}}, ISO8820, JASO-D622, RoHS raws |
Lus hais |
UL |
Dimension ntawm EV-HQ fuses
Tam sim no tus yam ntxwv nkhaus
Yam khoom
|
Qauv |
Rated tam sim no |
I²t(A²s) |
Kev siv fais fab |
Loj Code |
Nruab |
|
|
Pre-arc |
Fusing |
|||||
|
EV-HQ-80 |
80 |
5500 |
6400 |
15 |
VH 1 |
Mounting Bolt M8 pom zoo torque 11N·m |
|
EV-HQ-100 |
100 |
8700 |
10000 |
19 |
||
|
EV-HQ-125 |
125 |
15000 |
17810 |
23.5 |
||
|
EV-HQ-150 |
150 |
25000 |
29000 |
28 |
||
|
EV-HQ-175 |
175 |
40500 |
45000 |
33 |
||
|
EV-HQ-200 |
200 |
60300 |
68000 |
37 |
||
|
EV-HQ-225 |
225 |
83100 |
95000 |
40 |
||
|
EV-HQ-250 |
250 |
120000 |
138000 |
45 |
||
|
EV-HQ-275 |
275 |
173200 |
189000 |
48 |
||
|
EV-HQ-300 |
300 |
203000 |
243000 |
55.5 |
||
|
EV-HQ-350 |
350 |
252000 |
355000 |
62 |
||
|
EV-HQ-300 |
300 |
148500 |
260000 |
53.5 |
VH 2 |
Mounting Bolt M10 pom zoo torque 20N·m
|
|
EV-HQ-315 |
315 |
168000 |
280000 |
57 |
||
|
EV-HQ-350 |
350 |
203000 |
350000 |
61 |
||
|
EV-HQ-400 |
400 |
312000 |
496000 |
68 |
||
|
EV-HQ-500 |
500 |
550000 |
865000 |
78 |
||
Product System Code
FAQ
Q: Koj puas kuaj xyuas cov khoom tiav?
A: Yog lawm, txhua kauj ruam ntawm kev tsim khoom thiab cov khoom tiav yuav raug tawm los ntawm QC chav haujlwm ua ntej xa khoom.
Cim npe nrov: roj teeb them fuses, Tuam Tshoj, manufacturers, lwm tus neeg, Hoobkas
