450 amp fuse

Suav DC500V fuse daws hauv Roj Teeb Zog Cia System
Kev ntsuas hluav taws xob: DC 500V
Kev ntsuas tam sim no: 400A-1250A
Class: aR
Txuj: UL{0}}, ISO8820, JASO-D622, IEC60269, RoHS raws
Daim ntawv thov: luv-circuit thiab thaub qab tiv thaiv rau hluav taws xob tsheb tsav lub zog, lub zog hloov dua siab tshiab, lub zog cia thiab fais fab roj teeb, lub zog cia capacitor, inverter maub los, charger, MSD, hlau thiab lwm yam khoom siv tsheb thiab khoom siv.
If any further demand,pls feel free to contact by email:holly@delfuse.com or whatsapp by 8618813915908

Suav DC500V fuse daws hauv Roj Teeb Zog Cia System

Cov ntaub ntawv tseem ceeb ntawm 750VDC MEV-HF00 fuse

Dimension thiab kev ua tau zoo: GB13539, IEC60269, UL248

Rated Voltage: DC500V lossis qis dua

Rated Tam sim no: 315A / 450A / 630A; Chav Kawm Kev Tiv Thaiv: aR; Breaking Peev Xwm: DC20kA (lub sij hawm tas li Tsawg dua lossis sib npaug li 10ms)

Ua raws li EU thiab Tuam Tshoj RoHS cov lus qhia

Ua raws li cov cai ntawm QC / T413, ISO8820, JASOD622

Cov ntaub ntawv yam ntxwv

Qauv	Rated Tam sim no	Kev teeb tsa

MEV-HF00-315	315A	Mounting ntsia liaj qhov rooj M8 pom zoo torque 11N.m
MEV-HF00-450	450A
MEV-HF00-630	630A

Tag nrho qhov ntev ntawm 750VDC MEV-HF00 fuse

Qauv	A±1.5	B±1.5	C±1.5	D±0.5
MEV-HF00	51	44	50	20.5
MEV-HG00	59	44	51	24.5

MEV-H-F00 fuse

Product system code

Ambient Cua Kub

Kev siv li qub: -5 degree ~ 40 degree .

Tso cai tej yam kev mob: -40 degree -85 degree .

Kev hloov kho Parameter rau huab cua kub hloov pauv: ua haujlwm qis dua -5 degree, lub sijhawm ua ntej ntawm lub fuse qhov qis tshaj tam sim no txuas ntxiv me ntsis, thiab cov ntsuas tam sim no tau nce me ntsis. Tab sis tshwj tsis yog saum toj no -5 degree tsis nyob rau hauv qhov chaw ua haujlwm, feem ntau tsis xav txog qhov nce tam sim no ntawm fuse. Lub fuse ua haujlwm siab tshaj 40 degree, qhov ntsuas tam sim no xav tau kev kho ntxiv, thiab qhov kho qhov tseem ceeb yog -Kt.

Lus Cim 1: Tus nqi ntawm Kt tau coj mus rau hauv tus account qhov cuam tshuam ntawm qhov ntsuas kev nyab xeeb tam sim no ntawm lub fuse nyob rau hauv ib txwm ua haujlwm.

Lus Cim 2: Cov huab cua nyob ib puag ncig yuav tsum kav ntev dua 1 mus rau 2 teev ua ntej nws muaj kev cuam tshuam loj.

product-642-402

FAQ

Q: Puas yog MEV series khoom pom zoo los ntawm UL daim ntawv pov thawj?

A: Tam sim no Dissmann MEV series fuses kev pom zoo los ntawm TUV ntawv pov thawj, tab sis sai sai no yuav pom zoo los ntawm UL daim ntawv pov thawj thaum kawg ntawm Lub Rau Hli 2023
