Lub tshuab hluav taws xob photovoltaic muaj xws li photovoltaic square array (photovoltaic square array yog tsim los ntawm photovoltaic modules hauv series thiab parallel), xws li, roj teeb pob, DC / AC inverter thiab lwm yam. Lub hauv paus ntsiab lus ntawm photovoltaic fais fab tuag system yog photovoltaic modules, thiab photovoltaic modules yog tsim los ntawm photovoltaic hlwb nyob rau hauv series, parallel thiab encapsulated. Nws ncaj qha hloov lub teeb lub zog ntawm lub hnub mus rau hauv lub zog hluav taws xob.
Cov hluav taws xob tsim los ntawm photovoltaic modules yog tam sim no ncaj qha, uas tuaj yeem hloov mus rau hauv kev hloov tam sim no los ntawm inverter. Los ntawm ib qho kev pom, lub zog hluav taws xob uas tsim los ntawm lub tshuab hluav taws xob photovoltaic tuaj yeem siv tam sim ntawd, lossis lub zog hluav taws xob tuaj yeem khaws cia los ntawm cov khoom siv hluav taws xob xws li roj teeb, thiab tso tawm rau siv txhua lub sijhawm raws li xav tau.
Kev tsim cov khoom siv hluav taws xob xws li roj teeb yuav ua rau tus nqi ntawm cov tshuab hluav taws xob photovoltaic, thiab feem ntau yuav tsum tsis txhob txhawb nqa tshwj tsis yog rau lub hom phiaj tshwj xeeb.
